JSLA

App Requirements
Technology Strategy
HTML5 App Features & Limitations
System Architecture
RESTful server, socketio, and static files
Backbone Client App
Organizing a backbone project
Chat & sockets
Audio in the browser using aurora.js
Metadata from audio, album art
HTML sliders and progress bars, drag and drop
Uploading with xhr2
Vizualizing audio using dancer.js & d3
Mobile approach using media queries and user agent
Where to go from here?

App Requirements

HTML5 Web App
Audio Playback without Flash
Chat Rooms via Sockets
User Authentication
Media Server
Library Data
Queue Data

Technology Strategy

Open Source. Not targeting massive deployment to production. Experimenting with the technology.

HTML5 App Features & Limitations

Applications targeting the browser. HTML5, JS & CSS.

Browser compatability
URLs & SEO
App Stores
Device screen resolutions
Network connection, Offline & Caching

Resources

System Architecture

Server

House on Node.js
- Users & Auth
- Media Uploads
- Library Data & Queue
- Chat Room Sockets

Client

Backbone App View
- Nav View
- Media Player View
  - Player Controls
  - Player Information
  - Player Visualization
- Library View
  - Song List
    - Song Row
  - Song Upload
  - Song Search
- Queue View
  - Song Queue List
  - Song Played List
- Chat View
  - Room List
    - New Room Form
  - Open Room
    - Member List
    - Message List
    - Message Row
      - User Avatar & Name
      - Msg Txt
    - New Message Form

RESTful server, socketio, and static files

Backbone friendly REST endpoints:

Backbone application static files served from apps/jukebox/web to /jukebox

Backbone Client App

Organizing a backbone project

Require.js & Why AMD?

Example Bootstrap:

<html>
  <body>
    <div id="jukebox"></div>
    <script src="require.js"></script>
    <script>
    require(['jquery.js'], function(){
        require(['index.js'], function(webApp){
            webApp.init(function(jukebox){
                jukebox.setEl($('#jukebox'));
            });
        });
    });
    </script>
  </body>
</html>

// index.js
(function(){
    var app = {};
    app.init = function($el, callback) {
        require(['underscore.js'], function(){
            require(['backbone.js'], function(){
                require(['jukebox.js'], function(jukebox) {
                    if(callback) callback(jukebox);
                });
            });
        });
    }

    // use require module pattern
    if(define) {
        define(function () {
            return app;
        });
    }
})();

Backbone Components

Understand how Views, Models and Collections work together:

Views have a var $el, a render() function and can listen to dom events
Views often reference a Collection or Model. ex. ListView (has col) and RowView (has model).
Collections contain Models

Example:

var MyListView = Backbone.View.extend({

    initialize: function() {

        this.collection = new MyCollection();

        // listen for new documents to add to the list
        this.collection.on('add', function(doc){
            self.$el.append(doc.getView().el);
        });

        // load initial data from the server
        this.collection.fetch();
    },
    render: function() {
        this.$el.html('<ul></ul>');
        return this;
    },
    events: {
        "click": "alert"
    },
    alert: function() {
        alert('you clicked on the view el');
    }
});

var view = new MyView({el: $('#div-id')});

view.render();

Chat & sockets

Chat Server

var io = house.io.of('/socket.io/chat');

// user connection to chat
io.on('connection', function (socket) {

    // Ask for the room status
    socket.on('info', function(room_id, callback) {
        callback(roomInfo[room_id]);
    });

    // Manually advance the queue for a room
    socket.on('skip', function(data) {
        advanceRoomSongQ(data.roomId, true);
    });

    // Request to join a room
    socket.on('join', function(roomId) {
        // subscribe this socket (user) to this room
        socket.join(roomId);

        // tell the others in the room
        io.in(roomId).emit('entered', {room_id: roomId, user: roomUsers[roomId][socket.handshake.session.id]});

        socket.on('disconnect', function () {
          io.in(roomId).emit('exited', {room_id: roomId, user: roomUsers[roomId][socket.handshake.session.id]});
          socket.leave(roomId);
        });
    });
});

// example of saving a message on the server and emitting it to the chat room
var newMsg = {room_id, msg, user, at};
insertMessage(newMsg, function(err, data) {
    io.in(room_id).emit('message', newMsg);
});

Chat Client

// Backbone listens for messages
chat.MessageListView = Backbone.View.extend({
    initialize: function() {
        this.collection.on('add', function(doc, col) {
            $ul.append(doc.getView().render().el);
        });
    }
});

var socket = io.connect('http://localhost/socket.io/chat');

// join a room
socket.emit('join', room.get('id'));

// listen for messages
socket.on('message', function (data) {
    self.rooms[data.room_id].messageCollection.add(data);
});

Audio in the browser using aurora.js

Can I Use?: Audio API
Aurora on github
mp3, flac, alac, m4a, aac, ogg

Example:

var player = Player.fromURL('http://mysite.com/audio.wav');
var player = Player.fromFile(file);
player.play();

player.on('format', function(format){
    /*
    bitrate: 320000
    channelsPerFrame: 2
    formatID: "mp3"
    sampleRate: 44100
    */
});

player.on('duration', function(msecs){
    // update current song time
});

Metadata from audio, album art

Metadata from aurora:

player.on('metadata', function(metadata){
    /*
    album
    artist
    genre
    title
    trackNumber
    year
    */

    var src = window.URL.createObjectURL(metadata.cover.toBlob());
    $('.coverArt').append('<img src="' + src + '" />');
});

Uploading with xhr2

Example:

var formData = new FormData();
var xhr = new XMLHttpRequest();

formData.append('files', blobOrFile);

xhr.open('POST', '/api/files', true);

// Listen to the upload progress.
var progressBar = $row.find('progress');

xhr.upload.onprogress = function(e) {
  if (e.lengthComputable) {
    progressBar.val((e.loaded / e.total) * 100);
    progressBar.textContent = progressBar.value; // Fallback for unsupported browsers.
  }
};

xhr.onload = function(e) {
    console.log('upload complete');
    var data = JSON.parse(e.target.response);
};

xhr.send(formData);

HTML sliders and progress bars, drag and drop

Example:

<input class="rating" type="range" min="0" max="100" title="Rating" value="50">

<meter min="0.0" max="100.0" value="33.33"></meter>

Result:

Vizualizing audio using dancer.js & d3

Dancer API
Dancer patch to work with Aurora forked on github
Basic D3 Sample
Dancer.js & Aurora Example

Example:

var dancer = new Dancer();

var kick = dancer.createKick({
    onKick: function ( mag ) {
      console.log('Kick!');
      drawRadParticles(mag);
    },
    offKick: function ( mag ) {
      console.log('no kick :(');
      drawSadParticles(mag);
    }
  }).on();

Mobile approach using media queries and user agent

Target screen sizes using css media queries
Use browser user agent to determain iphone for limiting visualization
Not currently targeting network connection for media format & compression

Example of css media query to format app for smaller screens:

@media only screen and (min-width: 767px) {
    nav li:hover {
        color: green;
    }
}

Example:

if(window.navigator.userAgent.indexOf('iPhone') !== -1) {
    pageSize = 100;
} else {
    pageSize = 10; // load less on iphone
}

Where to go from here?

Other cool HTML5

Routing URLs
Can I Use?: History
Web Workers

TODO

Visualizations as plug-ins
Skins
Podcast player
Drag and drop images to chat
DJ more than the audio (visual, skin, etc)
Drag and drop queue
Round Robin Queue
Compress HTML app css & js.
Reference files remotely, without CORS
Youtube API
Last.fm

Thank you

Tell me what you think @comster and git the code at https://github.com/comster
